AFT MPM 05 200-1000 Litres
- Engine-Driven Water Mist
- Medium Working Pressure
- Suitable for Many Vehicle Types
- High Efficiency
- Digital Foam Regulation System
- Digital Control Panel
- Pressure: 40 bar
- Flow Rate: 55 Litres/min
Description
AFT’s MPM 05 utilizes AFT’s patented water mist technology to provide high extinguishing performance at a very low water consumption rate. The integrated digital foam injection system enables variable foam dosage.
The AFT MPM 05 fire fighting system is specially designed for application on pickups, small trucks, or trailers. Its compact design makes the MPM ideal for integration in rapid response vehicles and special solutions for operations in difficult-to-access terrain such as forests and mountainous regions.
The AFT MPM is also available as a compact version making it as powerful as a fire truck.
- Engine-Driven Water Mist
- Modular Plastic Water Tank 200-1000 Litres
- Medium Working Pressure
- Suitable for Many Vehicle Types
- High Efficiency
- Digital Foam Regulation System
- Digital Control Panel
- High-Precision Foam Mixing System
- External Suction from Water Sources (Lakes, Hydrants…)
- Jet and Spray Mode
- Easy to Operate
Technical Specifications
| Engine | |
| Petrol Engine | 2-Cylinder 4-Stroke Petrol Engine 16 HP / 11.9 kW at 3500 min⁻¹ Electric and Manual Starter |
| Battery | Maintenance-Free 12 V Battery |
| Pump | |
| Water Pump | High-Pressure Diaphragm Pump |
| Foam Additive | |
| Foam Mixing System | Digital Mixing Injection System |
| Filling Capacities | |
| Foam Tank | 25 Litres |
| Water Tank | Modular Water Tanks. Each Module Holds up to 200 Litres of Water. The tanks can be integrated into the Frame as Required. |
| Fuel Tank | 7.1 Litres |
| Technical Parameters | |
| Flow Rate | Max 55 Litres/min |
| Operating Temperature | Tmin +5°C; Tmax +60°C |
| Frames and Covers | Steel frame and steel plates with double powder coating. |
| Connections | 1,5″ C-coupling (Storz) 3/4″ D-coupling (Storz) |
| Hose | 30 m kink-proof hose on a steel reel with automatic retraction (DN 19; 3/4″) |
| Transportability | By Forklift |
| Extinguishing Gun | |
| Changeover Time | Approx. 2 sec. (Jet to Spray Mode) |
| Lancing Distance | Approx. 20-22 m Jet Mode Approx. 7-9 m Spray Mode |
| Working Pressure | 40 bar |
| Control Panel | |
| Display | Battery Charging Indicator Digital Filling Level Indicator for the Water Tank Digital Filling Level Indicator the Foaming Agent Tank Analog Filling Level Indicator for the Fuel Tank Working Hour Meter Revolution Counter Digital Pressure Gauge |
| Setting Options | Digital Set Point Device for the Foam Additive (Seven-segment Display in %) Two-Pole External Battery Charging Connection Choke and Throttle Button for Motor and System Start |
| Dimensions | |
| Weight Empty | Approx. 314 kg with 600 Litres Water Tanks |
| Dimensions (WxH) Control Panel | Approx. 1000 x 1280 mm |
| Dimensions (L) Tank Modules | 600 Litres 1500 mm 800 Litres 1750 mm 1000 Litres 2000 mm |
